Dedicated To Craftsmanship In Every Installation
Russett Glazing supplies and installs a complete line of architectural glazing systems. Every product on this page is selected for the same reason: it performs under real conditions, integrates cleanly with the rest of the building envelope, and gives architects and contractors the finishes and configurations they actually need to specify. From flush-glazed interior framing to thermally broken curtain walls and entrance doors, the systems below are built to balance long-term durability, thermal performance, and design flexibility on projects of any scale.
FRAMES
1450 Series
Interior Flush Glaze Framing System
A 1¾″ x 4½″ interior flush glaze framing system suited to a wide range of commercial interior partitions and glazed walls. The 1450 accepts both ¼″ (6mm) and ⅜″ (10mm) glazing and uses EPDM wedge gaskets to hold each lite securely.
Configuration options: add a 4½″ x 4½″ 90-degree corner post or a 4½″ x 4½″ high base sill where the layout calls for it. Compatible with standard swing door systems for a unified look.
Finishes: stocked in clear, bronze, and black anodized. Optional finishes include light bronze, medium bronze, champagne anodized, and powder or liquid paint.
1451 Series
Thermally Broken Flush Glazed Storefront
A 2″ x 4½″ thermally broken storefront engineered around a 6.6 polyamide glass fiber thermal break, delivering strong U-value performance for commercial and mixed-use exteriors. Built primarily for 1″ sealed insulating glass, with pocket-reducing adaptors available for ¼″, ⅜″, and ½″ glazing.
Performance details: a sloped glazing bead sheds water away from the glass pocket, while end dams and an integrated sill gutter direct moisture to weep holes for reliable drainage. The 4½″ x 4½″ 90-degree corner post provides clean, square sightlines.
Finishes: clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and custom paint optional.
Commercial Doors
218 Series Commercial Door
A narrow-stile commercial door built for the volume of foot traffic typical of retail plazas, mixed-use entries, and multi-family residential lobbies. Vertical stiles measure 2⅛″, with a 2⅜″ top rail and 4⅛″ bottom rail.
Glazing
¼″, ⅜″, ½″, or 1″ infill, including IGUs.
Hardware
accommodates the full range of commercial security hardware.
Rail flexibility
1″, 2⅜″, 4⅛″, 5½″, 7″, and 10″ rails can be specified as top, mid, or bottom rails.
Finishes
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and paint optional Integrates with the framing systems above.
350 Series Medium Stile Commercial Door
A medium-stile door sized for moderate to high-traffic commercial entries where the narrow-stile profile of the 218 isn’t enough. Vertical stiles measure 3½″, with a 4⅛″ top rail and a 5½″ bottom rail for added rigidity at the panic device line.
Glazing
¼″, ⅜″, ½″, or 1″ infill.
Hardware
compatible with maximum-security hardware packages.
Rail flexibility
optional rails in 1″, 2⅜″, 4⅛″, 5½″, 7″, and 10″, configurable as top, mid, or bottom rails.
Finishes
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and paint optional. Pairs cleanly with the 1450 and 1451 framing systems.
500 Series Commercial Door
A heavy-stile door specified for monumental and high-abuse openings: schools, courthouses, transit facilities, and government buildings. Vertical stiles measure 5″, with a 5½″ top rail and a 7″ bottom rail.
Glazing
¼″, ⅜″, ½″, or 1″ infill.
Hardware
built to carry the full weight of commercial security hardware, including continuous hinges and exit devices.
Rail flexibility
optional rails in 1″, 2⅜″, 4⅛″, 5½″, 7″, and 10″.
Finishes
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and paint optional. Compatible with all framing systems on this page.
Curtain Walls
5100 Series Curtain Wall System
A 2″ sightline non-thermal curtain wall sized for storefronts, lower-rise commercial, and institutional façades where structural performance and clean lines matter more than maximum thermal isolation. Mullion depths of 3″, 4″, and 5″ cover most spans.
Sealing: ¼″ silicone and EPDM gaskets manage air and water infiltration.
Fabrication: designed for efficient shop fabrication and on-site assembly to keep labour cost predictable.
Finishes: clear, bronze, and black anodized stocked. Light bronze, medium bronze, and champagne anodized optional. Integrates with the 218, 350, and 500 Series doors for full-system continuity.
5200 Series Curtain Wall System
A thermally broken curtain wall built on the same 2″ sightline as the 5100 but with a polyamide thermal break engineered into a roll-nose profile. The result is significantly improved U-values without giving up the slim sightline architects want for modern façades. Mullion depths of 3″, 4″, and 5″.
Performance: the polyamide break reduces thermal bridging and helps the wall meet current energy codes. The roll-nose profile adds rigidity against wind load.
Finishes: clear, bronze, and black anodized stocked. Light bronze, medium bronze, and champagne anodized optional. Suited to mid- and large-scale commercial, institutional, and multi-family projects.
6300 Series Curtain Wall System
A 2½″ sightline curtain wall offering a wider mullion range for taller spans and higher load conditions. Mullion depths of 4″, 5¼″, 6⅝″, and 8″ allow the system to scale from typical storefront heights up to multi-storey façades.
Sealing and glazing: ¼″ silicone with EPDM gaskets.
Fabrication: pre-engineered components reduce shop time and simplify field assembly.
Finishes: clear, bronze, and black anodized stocked. Light bronze, medium bronze, and champagne anodized optional. Pairs with all door systems above for a continuous façade detail.
6500 Series Curtain Wall System
The premium thermally broken curtain wall in the line, built around a high-performance polyamide thermal break. Specified for projects where energy code compliance, occupant comfort, and long-term operating cost are primary drivers, including office towers, institutional buildings, and high-end residential.
Thermal performance: the polyamide break delivers measurable U-value improvements over non-thermal systems, contributing meaningfully to whole-building energy modelling.
Durability: premium-grade aluminum and engineered components stand up to wind load, water infiltration, and air leakage testing.
Glazing: supports double-glazing and multi-panel configurations, including spandrel infill.
Finishes: clear, bronze, and black anodized stocked, with the full optional finish range available.
Insulroll Entrances
250
InsulRoll Thermally Broken Aluminum Door
A narrow-stile thermally broken entrance door for commercial openings where energy performance can’t be sacrificed at the door line.
Dimensions:
2½″ vertical stiles, 3⅛″ top rail, 4⅛″ bottom rail standard. Optional bottom rails of 5½″, 7″, and 10″.
Thermal performance:
an integrated thermal break interrupts conductive heat transfer through the door frame, supporting the building’s overall envelope performance.
Hardware:
accepts the full range of commercial entrance hardware.
Finishes:
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and custom paint optional. Specified for storefronts, offices, schools, and any commercial entry where a narrow-stile look is preferred.
350
InsulRoll Thermally Broken Aluminum Door
A medium-stile thermally broken entrance for commercial openings that need more visual weight and structural margin than the 250 provides.
Dimensions:
3½″ vertical stiles, 4⅛″ top rail, 5½″ bottom rail. Optional rails of 4⅛″, 5½″, 7″, and 10″.
Thermal performance:
thermally broken construction reduces conductive heat loss and condensation risk at the entrance.
Hardware:
compatible with the full commercial hardware range, including panic devices and continuous hinges.
Finishes:
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and paint optional.
500
InsulRoll Thermally Broken Aluminum Door
The heavy-stile thermally broken entrance, built for high-traffic and monumental openings that also need to perform thermally: schools, transit hubs, civic buildings, and tower lobbies.
Dimensions:
5″ vertical stiles, 5½″ top rail. Bottom rail specified at 7″ or 10″. Optional rails of 4⅛″, 5½″, 7″, and 10″ available for non-standard configurations.
Thermal performance:
thermal break technology delivers strong insulation values across temperature swings, suiting the door for cold-climate Canadian projects.
Hardware:
carries the full weight of commercial security and access hardware.
Finishes:
clear, bronze, and black anodized stocked. Light bronze, medium bronze, champagne anodized, and paint optional.
Frequently Asked Questions (FAQs)
What's the difference between the 5100 and 5200 curtain wall systems, and when should I spec each?
Both share a 2″ sightline and 3″, 4″, and 5″ mullion depths. The 5100 is non-thermal, suited to storefronts and lower-rise work. Spec the 5200 when energy code or thermal performance drives the design.
Which Russett door series is right for high-traffic commercial entrances: 218, 350, or 500?
The 218 (narrow stile) handles retail and lobby traffic. The 350 (medium stile) suits busier commercial entries needing more rigidity. The 500 (heavy stile) is built for monumental openings: schools, courthouses, transit, and civic buildings.
Are your products made in Canada?
Russett Glazing operates in Canada and supplies projects across the region. For specific manufacturing origin and country-of-fabrication documentation on a given system, contact us directly so we can confirm details for your project’s procurement requirements.
What glazing thicknesses do Russett framing and door systems accept?
Framing systems handle ¼″ (6mm) and ⅜″ (10mm), with the 1451 also taking 1″ sealed IGUs and ½″ via adaptors. All three commercial door series accept ¼″, ⅜″, ½″, and 1″ infill, including IGUs.
What finishes are available on Russett aluminum framing, doors, and curtain walls?
Stock finishes are clear, bronze, and black anodized. Optional finishes include light bronze, medium bronze, and champagne anodized. Framing and doors also support custom powder coat and liquid paint; curtain walls are anodized only.
Does Russett supply only, or supply and install, and what's the project intake process?
Russett supplies and installs. Intake starts with a consultation: share drawings, specs, and project scope, and we return system recommendations and a quote. Book a consultation or request a quote through the site to begin.
Are these glazing systems energy efficient?
Yes, when thermally broken systems are specified. The 1451 storefront, 5200 and 6500 curtain walls, and the 250, 350, and 500 InsulRoll doors use polyamide thermal breaks to reduce heat transfer and support energy code compliance.
Can Russett curtain wall systems integrate with the 218, 350, and 500 commercial doors?
Yes. The 5100, 5200, 6300, and 6500 curtain walls are designed to integrate with all three door series, giving architects continuous sightlines, consistent finishes, and unified hardware detailing across the full façade.
Are Russett's thermally broken systems suitable for Ontario climate and OBC energy code compliance?
Yes. The polyamide thermal breaks in the 1451, 5200, 6500, and InsulRoll doors reduce conductive heat loss and condensation risk, supporting OBC SB-10 envelope performance targets. Final compliance depends on glazing selection and whole-building energy modelling.
Spec a Russett Glazing System for Your Next Project
Structural integrity and safety are engineered directly into all our products. Our glazing systems are designed to ensure full regulatory compliance for any commercial project. Our framing, door, and curtain wall solutions provide a reliable foundation for your building. Deliver quality and lasting stability, protecting both your investment and the people who occupy it.
